Product Description
The Copeland Comfort Control 668-451 is an oil burner primary control. This device ensures the safe operation of oil burners in heating systems that require continuous ignition. The product features a metal enclosure and includes a line voltage safety switch that prevents prolonged burner operation in case of motor relay failure.
Includes a line voltage safety switch for safety.
Features solid-state flame detection circuitry.
Operates effectively in extreme temperatures, from -40 to 150 degrees Fahrenheit.
Product Highlights
The Copeland Comfort Control 668-451 is designed for robust performance and safety in oil burner applications.
Product Information
Standard Information
Input Voltage: 120 VAC, 60 Hz
Control Voltage: 24 VAC
Technical Specifications
Motor Relay Contacts Rating: Full 10 FLA, 60 LRA, 120 VAC
Ignition Transformer Rating: 360 VA (3.0A)
Safety Timing: 45 seconds
Suitable Temperature: -40 to 150 degrees Fahrenheit (-40 to 66 degrees Celsius)
Product DescriptionThe Copeland Comfort Control 668-451 is an oil burner primary control. This device ensures the safe operation of oil burners in heating systems that require continuous ignition. The product features a metal enclosure and includes a line voltage safety switch that prevents prolonged burner operation in case of motor relay failure.
Includes a line voltage safety switch for safety.
Features solid-state flame detection circuitry.
Operates effectively in extreme temperatures, from -40 to 150 degrees Fahrenheit.
Product HighlightsThe Copeland Comfort Control 668-451 is designed for robust performance and safety in oil burner applications.Product InformationStandard Information
Input Voltage: 120 VAC, 60 Hz
Control Voltage: 24 VAC
Technical Specifications
Motor Relay Contacts Rating: Full 10 FLA, 60 LRA, 120 VAC
Ignition Transformer Rating: 360 VA (3.0A)
Safety Timing: 45 seconds
Suitable Temperature: -40 to 150 degrees Fahrenheit (-40 to 66 degrees Celsius)
Vendor: COPELAND COMFORT CONTROL
Vendor Raw: COPELAND COMFORT CONTROL
Product Type: FURNACE CONTROL BOARDS
Availability Text: In Stock
Input Voltage: 120 VAC, 60 Hz
Control Voltage: 24 VAC
Motor Relay Contacts Rating: Full 10 FLA, 60 LRA, 120 VAC
Ignition Transformer Rating: 360 VA (3.0A)
Safety Timing: 45 seconds
Suitable Temperature: -40 to 150 degrees Fahrenheit (-40 to 66 degrees Celsius)
Tags: AI_Content, loc_2, Parcel
Source file: 668-451 - copeland-comfort-control-668-451-oil-burner-primary-control.json.json
| Input Voltage | 120 VAC, 60 Hz |
|---|---|
| Control Voltage | 24 VAC |
| Motor Relay Contacts Rating | Full 10 FLA, 60 LRA, 120 VAC |
| Ignition Transformer Rating | 360 VA (3.0A) |
| Safety Timing | 45 seconds |
| Suitable Temperature | -40 to 150 degrees Fahrenheit (-40 to 66 degrees Celsius) |
| Vendor | COPELAND COMFORT CONTROL |
| Vendor Raw | COPELAND COMFORT CONTROL |
| SKU | 668-451 |
| Tipo de producto | FURNACE CONTROL BOARDS |
| Disponibilidad | In Stock |
| Mensaje de envío | Ships Same Day if Ordered by 12 pm |
| Moneda | USD |
| Handle Shopify | copeland-comfort-control-668-451-oil-burner-primary-control |
| Shopify Product ID | 9881797132594 |
| Peso | 3 lb |
| Peso gramos | 1361 |
| Tags | AI_Content, loc_2, Parcel |
