A210-30-11-84, Controlador de 3 puntos, 110 V/50 Hz, 110-120 V/60 Hz.
| Coil Volts | 110 to 120V |
|---|---|
| HP @ 3 Phase - 208V | 60 hp |
| HP @ 3 Phase - 240V | 75 hp |
| HP @ 3 Phase - 480V | 150 hp |
| Aux. Contact Configuration | 1NO, 1NC |
| Hz | 50/60 Hz |
| Width | 140 mm |
| Height | 227 mm |
| Depth | 180.5 mm |
| Mechanical Durability | 5 Mcycles |
| Working Height | 3,000 m |
| Hold VA | 60 VA (at 50 Hz), 65 VA (at 60 Hz) |
| IP Rating | IP20, IP00 |
| Electrical Connection | Bars |
| Impulse Withstand Voltage | 8 kV |
| Rated Voltage | 690V |
| Operating Time | 7 to 13 ms (Coil De-energization and NC Contact Closing), 10 to 16 ms (Coil De-energization and NO Contact Opening), 12 to 30 ms (Coil Energization and NC Contact Opening), 17 to 35 ms (Coil Energization and NO Contact Closing) |
| Rated Insulation Volts | 600/1000V |
| Thermal Amperage | 350 A (at 40°C) |
| Max. Operating Watts | 110 kW (at 380/400V, 415V, 440V), 132 kW (at 500V), 160 kW (at 690V), 59 kW (at 220/230/240V) |
| Control Circuit Voltage Limits | 0.85 to 1.1 Uc |
| Rated Short-Time Withstand Current | 1700 A (at 40°C for 10 s), 400 A (at 40°C for 15 min), 1000 A (at 40°C for 1 min), 2500 A (at 40°C for 1 s), 1200 A (at 40°C for 30 s) |
| Net Weight | 5.4 kg |
| Package Quantity | 1 |
