Compression Lug, 250 Kcm, L 2.60 In, Ylw
| Cable Size | 250 kcmil |
|---|---|
| Connector Type | Standard Barrel |
| Width | 1.13 in |
| Material | Electro-Tin Plated High-Conductivity Wrought Copper |
| Length | 2.6 in |
| Color Code | Yellow |
| Peep Hole | Yes |
| Item | One-Hole Lug Compression Connector |
| Hole Center to Center | Not Applicable |
| Standards | CSA Certified, UL Listed |
| Die Code | 62 |
| Stud Size | 1/2 in |
| Color | Yellow |
| For Conductor Material | Copper |
| For Wire Type | Stranded |
| For Stranded Copper Wire Size - Maximum | 250 kcmil |
| Inspection Hole | Yes |
| Barrel Size | Standard |
| For Stud Size | 1/2 in |
| Maximum Voltage | 35 kV AC |
| Insulated | No |
| Number of Holes | 1 |
| Type | Standard Barrel |
| Voltage Rating | 35 kV |
| Insulation | None |
| Standard | UL E9809 |
| Connecting angle | 180° |
| Surface protection | Tinned |
| Package Quantity | 1 |
