Control Transformer, 200 VA, Not Rated, 115/24V AC, 208/230/460V AC
| Item | Control Transformer |
|---|---|
| Input Voltage - Transformer | 208/230/460V AC |
| Mounting - Transformer | Foot, Plate |
| Hz - Electrical | 50/60 Hz |
| Color | Black |
| Enclosure Finish | Epoxy Resin Varnish |
| Output Voltage - Transformer | 115/24V AC |
| Protective Device | Primary and Secondary Fuse |
| Enclosure Style - Transformer | Open |
| Phase - Electrical | 1 |
| Depth | 4.47 in |
| Standards | cUL Listed, UL Listed |
| Temp. Rise | Not Rated |
| VA Rating - Transformer | 200 VA |
| Height | 5.29 in |
| Manufacturers Warranty Length | 20 yr |
| Width | 4-1/2 in |
| Includes | Factory Installed Primary Fuse Block and Secondary Fuse Clips |
| Weight | 9.8 lb |
| Pallet Quantity | 120 |
| Carton Quantity | 1 |
| Primary Voltage | 208/230/460 V |
| Certified Listed | UL ListedcUL Listed |
| Application | Acme's TB Series Industrial Control Transformers are especially designed to accommodate the momentary current inrush caused when electromagnetic components are energized... without sacrificing secondary voltage stability beyond practical limits.The transformer's windings and internal terminations are encased in a durable thermoplastic end cap, protecting them from potentially damaging moisture, dirt and other ambient contaminants. Acme's TB Series transformers are dry-type, step-down transformers with the secondary control circuit isolated from the primary line circuit to assure maximum safety. |
| Features | Encapsulated design protects core & coil assembly from potentially damaging contaminants; Constructed with high quality silicon steel lamination to minimize core losses and increase efficiency; Integrally molded terminal blocks with isolation barriers to prevent arc over |
| Package Quantity | 1 |
