Toroidal Transformer, 30 kVA, NEMA 3R, 115°C, 120/208V, 480V
| Item | Toroidal Transformer |
|---|---|
| Input Voltage - Transformer | 480V |
| Mounting - Transformer | Wall |
| Hz - Electrical | 60 |
| Enclosure Rating | NEMA 3R |
| Depth | 13-3/4 in |
| VA Rating - Transformer | 30 kVA |
| Temp. Rise | 115 deg C |
| Height | 43-3/4 in |
| Phase - Electrical | 3 |
| Winding Material - Transformer | Aluminum |
| Output Voltage - Transformer | 120/208V |
| Width | 33 in |
| Electrostatic Shield | Shielded |
| Primary Breaker | ED43B090L (90A) |
| Max Temperature Rise | 115 Degrees Celsius |
| CSA Standard | C22.2 No 47 |
| UL Insulation Class | 180°C |
| BNFC Taps | 2 |
| Secondary Breaker | Q3100 (100A) |
| Primary Voltage | 480D V |
| UL Standard | UL 1062 |
| Taps % Steps | 0.05 |
| Construction | Encapsulated |
| Material type | ZFIN |
| Carton Quantity | 1 |
| Product Category | Panel-Tran Zone Power Centers |
| Package Quantity | 1 |
