Adhesive Dots, EP2400 Series, Clear, 1/2 in (Round), Dot, 1:01 Mix Ratio, 30 min Functional Cure
| Item | Adhesive Dots |
|---|---|
| Type | Conductive |
| Application | For Bearing Protection Ring Installation |
| Color | Clear |
| For Use On | Mfr. No. 14R028 thru 14R037 |
| Container Size | 1/2 in (Round) |
| Container Type | Dot |
| Functional Cure | 30 min |
| Full Cure | 4 hr |
| Mixing Ratio | 1:01 |
| Shear Strength | 4,000 psi |
| Temp. Range | 55 to 80 deg F |
| Working Time | 5 min |
| Series | EP2400 |
| Epoxy Color | Yellow |
| Work Life | 5 min |
| For Use With | Mfr. No. 14R028 thru 14R037 |
| Shear Strength (PSI) | 4,000 |
| Temp. Range (F) | 55 to 80 |
| Structural Adhesive Type | Epoxy Adhesive |
| Epoxy Max. Temp | 199 Degrees F and Below |
| Epoxy Container | Syringe |
| Coverage | 4 sq in |
| Size | 0.5 fl oz |
| Includes | 2 Part Epoxy |
| Resin Type | Epoxy |
| Application Method | Brush On |
| Resin Color | Gray |
| Included Components | Hardener, Resin |
| VOC Content Weight | 9.92 g/L |
| Standards | ISO 9001, OSHA 29 CFR 1910.1200, UL Certified |
| Non-Sagging | Yes |
| Minimum Viscosity | 15,000 cps |
| Hardener Color | Silver |
| VOC Content Weight Percentage | 50% |
| Marine Grade | No |
| Features | Electrical Conductivity, Faster Curing Time |
| Cured Color | Gray |
| Maximum Performance Temperature | 150 deg C |
| Maximum Application Temperature | 80 deg F |
| Low Odor | No |
| Water Resistance | Water-Resistant |
| Primary Applications | Bearing Rings |
| Full Cure Time | 4 hr |
| Materials Bonded | Metal |
| Minimum Application Temperature | 55 deg F |
| Maximum Viscosity | 15,000 cps |
| Total Volume | 0.5 fl oz |
| Interior/Exterior | Exterior, Interior |
| Container Type - Adhesives | Syringe |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
