Power Inverter and Battery Charger, Pure Sine Wave, 3,000 W Peak, 1,000 W Continuous, 2 Outlets
| Item | Power Inverter and Battery Charger |
|---|---|
| Peak Output Power | 3,000 W |
| Continuous Output Power | 1,000 W |
| Inverter Output Form | Pure Sine Wave |
| Inverter Input Voltage | 12V DC |
| Inverter Output Voltage | 120V AC |
| Outlet Type | GFCI |
| DC Connection | Terminal Bock |
| Number of Outlets | 2 |
| Depth | 7.1 in |
| Includes | Inverter Charger |
| Nominal Output Power | 1,000 W |
| Length | 15-1/2 in |
| Standards | N/A |
| Application | Off-grid home back up power, solar systems, business back-up power, campsites, tailgating parties or any recreational locations |
| Features | 1000 watt low frequency inverter, 3000 watt surge for 20 seconds 300% surge capability, Battery priority selector, Terminal block, GFCI outlet – 10 amps, Marine coated and protected, Multi stage smart charger 35 Amp for gel, AGM, lead and lithium LiFePO4, Remote panel available, Auto frequency, 10msec typical transfer time, Selectable 25W power save mode (hibernation), 7 battery type settings for charger, Automatic transfer switch |
| Width | 8.74 in |
| Specification | Specifications:Inverter Output Specifications: Input Specifications;Charger Specifications;Transfer Switch Specifications;Dimensions;Continuous Output Power: 1000 Watts;Surge Rating: 3000 Watts (20 Seconds);Output Waveform: Pure Sine/Same as input (Bypass Mode);Nominal Efficiency: >88% (Peak);Line Mode Efficiency: >95%;Output Frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz;Typical Transfer Time: 10ms (Max);Bypass Breaker – 20 amps;THD: < 10% DC;Ambient operating temperature: 14°F to 122°F (-10°C to 50°C);Nominal Input Voltage: 12.0Vdc;Minimum Start Voltage: 10.0Vdc;Low Battery Alarm: 10.5Vdc-11.0Vdc;Low Battery Trip: 10.0Vdc-10.5Vdc;High Voltage Alarm: 16.0Vdc;Low Battery Voltage Restart: 13.3Vdc;Idle Consumption: < 12.5 watts;Charger Breaker 10 amps;Power Saver Mode Idle Consumption: <7.5 wattsC;Output Voltage: Depends on battery Type;Charger Rate: 35A;Over Charge Protection Shutdown 15.7V;Selectable Charge Setting Dial;Adjustable Charge Current: off-20%-100%;Four Stage Smart Charger;30 amp auotmatic transfer switch;10 ms (max);Unit Weight: 35 lbs.;Unit Size L x W x H: 14.1 x 8.74 x 7.10 inches;Shipping Weight: 39 lbs.;Shipping L x W x H 20.75 x 12.75 x 12.50 inches |
| Line Mode Efficiency | >95% |
| Nominal Efficiency | >88% (Peak) |
| Color | Blue |
| Package Quantity | 1 |
