AC 14C 1416 PIN PLUG
| Item | Pin & Sleeve Plug |
|---|---|
| Sealing | Unsealed |
| Connector Style | Plug |
| Contact Size | 14#16 |
| Operating Voltage AC V RMS Max | 500 |
| Mounting Type | Cable |
| Insert Rotation/Keying | Normal |
| Orientation | Straight |
| Operating Temperature °F (°C) | -67 - +257 (-55 to +125) |
| Insert Arrangement | 20-27 |
| Grommet & Seals Material | Neoprene |
| Contact Style | Pin |
| Insert Material | Neoprene |
| Shell Plating | Olive Drab Cadmium |
| Endbell Type | Threaded - UNEF - Ext |
| Contact Material | Alloy |
| No. of Contacts | 14 |
| Shell Material | Aluminum Alloy |
| Shell Color | Olive Drab |
| Connector Type | Circular |
| Service Rating | A |
| Termination Method | Crimp |
| Contact Plating | Silver |
| Shielding | Yes |
| Contact Mating Life | 500 |
| Operating Voltage DC | 700 |
| Contacts Supplied | Yes |
| Crimp Wire Gauge | 16, 20, 18 |
| Package Quantity | 1 |
