NEOPRENE SPRING, HANGERS 1, LD 115-170LB
| Item | Spring Hanger |
|---|---|
| Width | 3 in |
| Spring Color | Silver |
| Height | 8 in |
| Spring Identifier Color | Red, Yellow |
| Rated Deflection | 1.3 in |
| Rated Load | 149LBS |
| Features | Design allows angular hanger misalignment The assembly incorporates dual (Steel and Elastomer) washers for uniform load distribution and high frequency isolation. These spring hangers are normally used in critical areas where noise and vibration need to be controlled. Springs have 50% additional travel to max load as per ASHRAE recommendations. |
| Application | These spring hangers are normally used in critical areas where noise and vibration need to be controlled |
| For Use With | Fan Coil Units, Air Handling Units, Fans, Pipes, Ducts |
| Length | 3 in |
| Max Load | 225 lb |
| Finish | Spring: Galvanized; Bracket: Powder Coated, Colour Coded Neoprene Element |
| Includes | Steel Spring, Steel Bracket, Steel and Elastomer Washers, Neoprene Cup, Neoprene Element |
| Capacity | 149 lb |
| Color | Blue |
| Material | Elastomeric Compounds, Powder Coating, Spring Steel; High Strength Low Carbon Alloy Steel |
| Package Quantity | 1 |
