NEOPRENE SPRING, HANGERS 1, LD 225-340LB
| Item | Spring Hanger |
|---|---|
| Spring Color | Silver |
| Height | 8 in |
| Width | 3 in |
| Material | Elastomeric Compounds, Powder Coating, Spring Steel; High Strength Low Carbon Alloy Steel |
| Rated Load | 297LBS |
| Features | Design allows angular hanger misalignment The assembly incorporates dual (Steel and Elastomer) washers for uniform load distribution and high frequency isolation. These spring hangers are normally used in critical areas where noise and vibration need to be controlled. Springs have 50% additional travel to max load as per ASHRAE recommendations. |
| Finish | Spring: Galvanized; Bracket: Powder Coated, Colour Coded Neoprene Element |
| Capacity | 297 lb |
| Application | These spring hangers are normally used in critical areas where noise and vibration need to be controlled |
| For Use With | Fan Coil Units, Air Handling Units, Fans, Pipes, Ducts |
| Rated Deflection | 1 in |
| Color | Blue |
| Includes | Steel Spring, Steel Bracket, Steel and Elastomer Washers, Neoprene Cup, Neoprene Element |
| Length | 3 in |
| Max Load | 450 lb |
| Spring Identifier Color | Green, Red |
| Package Quantity | 1 |
