NEOPRENE SPRING, HANGERS 1, LD 300-450LB
| Item | Spring Hanger |
|---|---|
| Spring Color | Silver |
| Width | 3 in |
| Height | 8 in |
| Features | Design allows angular hanger misalignment The assembly incorporates dual (Steel and Elastomer) washers for uniform load distribution and high frequency isolation. These spring hangers are normally used in critical areas where noise and vibration need to be controlled. Springs have 50% additional travel to max load as per ASHRAE recommendations. |
| Capacity | 396 lb |
| Length | 3 in |
| Material | Elastomeric Compounds, Powder Coating, Spring Steel; High Strength Low Carbon Alloy Steel |
| Includes | Steel Spring, Steel Bracket, Steel and Elastomer Washers, Neoprene Cup, Neoprene Element |
| Finish | Spring: Galvanized; Bracket: Powder Coated, Colour Coded Neoprene Element |
| Rated Load | 396LBS |
| Color | Blue |
| Max Load | 600 lb |
| For Use With | Fan Coil Units, Air Handling Units, Fans, Pipes, Ducts |
| Spring Identifier Color | Green, Purple |
| Application | These spring hangers are normally used in critical areas where noise and vibration need to be controlled |
| Rated Deflection | 1.2 in |
| Package Quantity | 1 |
