NEOPRENE SPRING, HANGERS 1, LD 375-560LB
| Item | Spring Hanger |
|---|---|
| Height | 8 in |
| Spring Color | Silver |
| Width | 3 in |
| Application | These spring hangers are normally used in critical areas where noise and vibration need to be controlled |
| Capacity | 495 lb |
| Finish | Spring: Galvanized; Bracket: Powder Coated, Colour Coded Neoprene Element |
| For Use With | Fan Coil Units, Air Handling Units, Fans, Pipes, Ducts |
| Includes | Steel Spring, Steel Bracket, Steel and Elastomer Washers, Neoprene Cup, Neoprene Element |
| Spring Identifier Color | Black, Orange |
| Color | Blue |
| Material | Elastomeric Compounds, Powder Coating, Spring Steel; High Strength Low Carbon Alloy Steel |
| Features | Design allows angular hanger misalignment The assembly incorporates dual (Steel and Elastomer) washers for uniform load distribution and high frequency isolation. These spring hangers are normally used in critical areas where noise and vibration need to be controlled. Springs have 50% additional travel to max load as per ASHRAE recommendations. |
| Rated Deflection | 1.2 in |
| Length | 3 in |
| Rated Load | 495LBS |
| Max Load | 750 lb |
| Package Quantity | 1 |
