Smart UPS, 1.5kVA, Line Interactive, Out: 120V AC In: 120V AC
| Item | Smart UPS |
|---|---|
| UPS Type | Line Interactive |
| Power Rating | 1.5 kVA |
| Mounting | Rack |
| Wattage | 1 kW |
| Input Voltage | 120V AC |
| Output Voltage | 120V AC |
| Backup Time (Half/Full Load) | 35 min/10 min |
| Outlet Type | (6) UPS/Surge |
| Medical Grade | No |
| Number of Outlets | 6 |
| Special Features | Automatic Battery and UPS Self-Testing, AVR Boost and AVR Trim Automatic Voltage Regulation, Rack Height 2 U |
| Depth | 18 in |
| Width | 18 in |
| Automatic Volts Regulation | Yes |
| Green Environmental Attribute | Product is Rechargeable |
| Input Current | 12 A |
| NEMA Receptacle Configuration | 5-15R |
| Transfer Time | 2 to 4 msec at High Sensitivity |
| Height | 4 in |
| Hz | 50/60 Hz ( +/-3 Hz) |
| Display Type | LCD |
| Phase | Single |
| Includes | Rack Mounting Support Rails, USB Cables |
| Fax/Modem Line Protection | No |
| Ports | Smart Slot, USB |
| VA Rating - UPS Systems | 1.5 kVA |
| NEMA Plug Configuration | 5-15P |
| Standards | cULus, ENERGY STAR V2.0 (USA), RoHS |
| Footnotes | 4,7 |
| Cord Length | 8 ft |
| Capacity - Batteries | 1440 VA/1000 W |
| Battery Type | Lead Acid |
| Housing Color | Black |
| Voltage | 120 |
| Overall Width | 43.2 cm |
| Input Connection | 8 ft Cord with NEMA 5-15P Plug |
| Housing Material | Steel |
| Typical recharge time | 3 |
| Surge Energy Rating | 459 |
| Output Power Capacity, VA | 1,440 |
| Input Connection Type | NEMA 5-15P |
| Nominal Output Voltage | 120V |
| Rack Height | 2 |
| Interface Port(s) | RJ-45 Serial,SmartSlot,USB |
| Mount Position | Front |
| Output Connections | 6 |
| Waveform type | wave |
| Approvals | CSA |
| Thermal Dissipation | 65.94 W |
| Output Frequency | 60 Hz |
| Alarm | Configurable Delay, Low Battery |
| Network Management | SmartSlot |
| Operating Humidity | 0% - 95% |
| Battery Life | 6 yr |
| Number of Battery & Surge Outlets | 6 |
| Load Capacity | 1440 VA/1000 W |
| Number of Batteries | 1 |
| Sound Emission (A-Weighted) | 45 dB |
| Storage Temperature | 41°F (5°C) - 235.4°F (113°C) |
| Battery Energy | 1555.2 kJ |
| Input Frequency | 60 Hz |
| USB (HID Compliant) Port | Yes |
| Network (RJ-45) | Yes |
| Maximum Operating Temperature | 104°F |
| Maximum Storage Elevation | 50,000 ft |
| Status Indicators | LCD Status |
| Serial Port | Yes |
| Package Contents | Smart-UPS 1500VA LCD RM 2U 120V with SmartConnect , Installation guide, Rack mounting support rails, USB cable |
| Maximum Operating Elevation | 10,000 ft |
| Typical Battery Recharge Time | 3 hr |
| Input Voltage Range | 82 AC to 144 V AC |
| Form Factor | Rack-mountable |
| Input Current - Maximum | 12 A |
| Operating Temperature - Maximum | 104 deg F |
| Battery Recharge Time | 3 hr |
| External Battery Compatible | External Battery Pack Compatible |
| Output Ports Included | USB |
| Automatic Voltage Regulation | Includes Automatic Voltage Regulation |
| Replacement Battery Part Number | APCRBC159 |
| Operating Temperature - Minimum | 32 deg F |
| Manufacturer Warranty | 3 yr |
| Surge Suppression Rating | 680 J |
| Power Cord Length | 8 ft |
| Audible Alarm Conditions | Low Battery |
| Power Rating - Real | 1 kW |
| Includes Battery | Battery Included |
| Package Quantity | 1 |
