UPS System, 500VA, Standby, Out: 120V AC In: 120V AC
| VA Rating - UPS Systems | 500 VA |
|---|---|
| Item | UPS System |
| UPS Type | Standby |
| Power Rating | 500 VA |
| Mounting | Floor |
| Wattage | 300 W |
| Input Voltage | 120V AC |
| Output Voltage | 120V AC |
| Backup Time (Half/Full Load) | 13 min 29 sec/3 min 24 sec |
| Outlet Type | (3) Surge; (3) UPS/Surge |
| Medical Grade | No |
| Number of Outlets | 6 |
| Cord Length | 6 ft |
| Width | 11 in |
| Green Environmental Attribute | Product is Rechargeable |
| Ports | USB |
| Hz | 50/60 Hz ( +/-3 Hz) |
| Footnotes | 2,4,6 |
| Height | 7 in |
| Includes | CD with Software, Cord Management Straps, USB Cables |
| Display Type | LED |
| Depth | 11 in |
| NEMA Receptacle Configuration | 5-15R |
| Input Current | 12 A |
| Standards | RoHS |
| Transfer Time | 8 to 10 msec |
| Fax/Modem Line Protection | Yes |
| Phase | Single |
| NEMA Plug Configuration | 5-15P |
| Special Features | LED Indicators Provide Proactive Notification of Changing Power and UPS Conditions |
| Automatic Volts Regulation | No |
| Housing Color | Black |
| Battery Type | Sealed Lead Acid |
| Capacity - Batteries | 500 VA/300 W |
| Voltage | 120 |
| Overall Width | 9.1 cm |
| Input Connection | NEMA 5-15P Plug |
| Housing Material | Steel |
| Product Certifications | cUL Listed || California (CEC) Battery Charger || ENERGY STAR V2.0 (USA) || Industry Canada |
| Ambient Air Temperature For Operation | 0 to 40°C |
| Rated Power In Va | 500 VA |
| Input Frequency | 50/60 Hz +/- 3 Hz auto-sensing |
| Mounting Location | front |
| Ambient Air Temperature For Storage | -15-45°C |
| Storage Altitude | 0-50000 ft |
| Kw Rating | 300 W |
| Operating Altitude | 0...10000 ft |
| Alarm | alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| Acoustic Level | 45 dBA |
| Number Of Cables | 1 |
| Provided Equipment | CD with software || Cord management straps || User Manual || USB cable |
| Battery Life | 4-6 year(s) |
| Usb Compatible | Yes |
| Relative Humidity | 0-95 % |
| Efficiency At Full Load | 98...140 V |
| Online Thermal Dissipation | 24 Btu/h |
| Control Panel | LED status display with on line : on battery : replace battery and overload indicators |
| Package Contents | Back-UPS CS 500VA Tower UPS , CD with software, Cord management straps, USB cable, User manual |
| Additional Information | Lifetime data recovery warranty, Serial Connectivity, USB connectivity |
| Battery Characteristics | Spill-proof, Maintenance-free |
| Waveform Type | Stepped Sine Wave |
| Load Capacity | 500 VA/300 W |
| Typical Battery Recharge Time | 8 hr |
| Form Factor | Tower |
| Product Series | CS |
| USB | Yes |
| Surge Energy Rating | 480 J |
| Dataline Protection | RJ-11 |
| Number of Battery & Surge Outlets | 6 |
| Data Line Protection | Includes Data Line Surge Protection |
| Automatic Voltage Regulation | No Automatic Voltage Regulation |
| Power Rating - Real | 300 W |
| External Battery Compatible | Not External Battery Pack Compatible |
| Output Ports Included | USB |
| Manufacturer Warranty | 3 yr |
| Operating Temperature - Minimum | 32 deg F |
| Power Cord Length | 6 ft |
| Input Current - Maximum | 12 A |
| Includes Battery | Battery Included |
| Replacement Battery Part Number | RBC2 |
| Operating Temperature - Maximum | 104 deg F |
| Battery Recharge Time | 8 hr |
| Surge Suppression Rating | 480 J |
| Audible Alarm Conditions | Low Battery |
| Package Quantity | 1 |
