Electrical Box, Mounting Box Type, 3 Gangs, Malleable Iron
| Item | Electrical Box |
|---|---|
| Capacity | Not Applicable |
| Box Type | Mounting |
| Number of Gangs | 3 Gangs |
| Material | Malleable Iron |
| Width | 3.72 in |
| Depth | 3.06 in |
| Conduit Size | 1 in |
| Color | Gray |
| Hub Size | 1 in |
| Hub Style | Feed-Thru |
| Standards | UL 894, UL 1203, UL Listed for Class I, Division 1, Groups C, D; Class I, Division 2, Groups B, C, D; Class II, Division 1 and 2, Groups E, F, G; and Class III |
| Height | 8.34 in |
| Includes | Internal Ground Screw |
| Clamp Type | Clamp Not Included |
| Bracket Type | Lugs |
| IP Rating | Not Applicable |
| Overall Height | 9-3/16 in |
| Overall Width | 3-3/4 in |
| Ceiling Fan Rated | Not Rated |
| For Construction Type | New Construction, Remodel |
| Overall Depth | 3-1/16 in |
| Number of 1/2 in Back Knockouts | 0 |
| Number of 1/2 in Side Knockouts | 0 |
| Hazardous Location Specification | Class I, Div 1 and 2, Group C, D, Class II, Div 1 and 2, Group E, F, G, Class III, Div 1 and 2 |
| NEMA Enclosure Rating | 3, 7CD, 9EFG |
| Box Height | 7-1/2 in |
| Box Diameter | Not Applicable |
| Box Shape | Rectangular |
| Number of 1 in Side Knockouts | 0 |
| Hub Type | Feed Through |
| Number of 3/4 in Back Knockouts | 0 |
| Number of 3/4 in Side Knockouts | 0 |
| Package Quantity | 1 |
