Este conector eléctrico de alta calidad y gran resistencia es ideal para aplicaciones industriales y comerciales. Con capacidad de 20 amperios y resistente a condiciones adversas.
| Item | Plug |
|---|---|
| Voltage | 240 V AC |
| NEMA Rating | 3, 3R, 7BCD, 9FG |
| Amps | 20 |
| Standards | UL Listed |
| HP | 2 HP |
| Number of Wires | 2 |
| Number of Poles | 3 |
| NEMA Type | 6-20P |
| Material | Copper-Free Aluminum |
| Hz | 60 |
| Housing Material | Metallic |
| Number of Blades | 3 |
| Grounding | Grounded |
| Polarized | No |
| Blade Material | Brass |
| Connection Orientation | Straight |
| Wire Connection Type | Screw Terminals |
| For Environment | Hazardous Location |
| Resistance Properties | Corrosion Resistant |
| Market | Commercial |
| For Maximum Cable Diameter | 0.639 in |
| Shrouded | No |
| IP Rating | Not Rated |
| For Minimum Cable Diameter | 0.538 in |
| Face Diameter | 1-3/4 in |
| NEMA Plug Configuration | 6 to 20 P |
| Horsepower Rating | 2 HP |
| Housing Color | Gray |
| Grade | General Use |
| Current Rating | 20 A |
| Voltage Rating | 250V AC |
| NEMA Enclosure Rating | 4 |
| Hazardous Location Specification | Class I, Div 1 and 2, Group B, C, D, Class II, Div 1 and 2, Group F, Class III, Div 1 and 2 |
| Overall Length | 2.78 in |
| Wiring Style | Standard |
| Body Length | 2.78 in |
| Phase | Single |
| Outside Diameter | 1.52 in |
| Compatible with Series | ECC, ECCL, ECH, ECHT, ECS, N1, N2 |
| UL 94 Flammability Rating | Not Rated |
| Maximum Wire Size | Not Applicable |
| Minimum Wire Size | Not Applicable |
| Insulation Material | Thermoplastic |
| Package Quantity | 1 |
