Multi-conductor Cable, 22 AWG, 4 C, Black, PVC, Stranded, 300V AC
| Item | Multi-conductor Cable |
|---|---|
| Wire Size | 22 AWG |
| Number of Conductors | 4 |
| Conductor Design | Stranded |
| Jacket Material | PVC |
| Jacket Color | Black |
| Length | 5,000 ft |
| Voltage | 300 V |
| Conductor Material | Copper |
| Standards | CEC/C(UL) CM; CSA FT1; UL 1685 UL Loading |
| Outside Dia. | 0.35 in |
| Temp. Rating | 60°C |
| Shielding Material | Tinned Copper |
| Stranding | 7 x 30 |
| Insulation Material | Polyethylene |
| Max. Voltage | 300 V |
| Shielding | Foil, Braid |
| Insulated / Uninsulated | Insulated |
| NEC Article and Type | CM, PLTC |
| Shielded | Shielded |
| Impedance | 120 ohms (Nominal Impedance) |
| CSA | FT1 VERTICAL FLAME TEST |
| Screen/Shield | Yes |
| Plenum | General Purpose |
| NEC Rating | UL LISTED ART 800 |
| Construction | Braid/Mylar/Braid Overall Dbl Braid |
| Spec Nbr Ul Style | UL LSTED WIRE MISC. |
| Package Quantity | 1 |
