Multi-Conductor Cable, 24 AWG, 4 C, Red, FEP, Stranded, 300V AC
| Item | Multi-Conductor Cable |
|---|---|
| Wire Size | 24 AWG |
| Number of Conductors | 4 |
| Conductor Design | Stranded |
| Jacket Material | FEP |
| Jacket Color | Red |
| Voltage | 300 V |
| Conductor Material | Copper |
| Standards | CEC/C(UL) CMP; NFPA 262, UL 910 (Plenum) |
| Shielding Material | Tinned Copper |
| Fire Rating - Data Cable | Plenum |
| NEC Article and Type | CMP |
| Insulation Material | Fluorinated Ethylene Propylene |
| Max. Voltage | 300 V |
| Stranding | 7 x 32 |
| Shielded | Shielded |
| Shielding | Foil, Braid |
| Insulated / Uninsulated | Insulated |
| Temp. Rating | 200°C |
| Screen/Shield | Yes |
| CSA | FT6 HORIZONTAL FLAME & SMOKE TEST |
| Construction | Overall Foil & Braid |
| Package Quantity | 1 |
