High Velocity Air Curtain, 4678 cfm
| Item | Unhtd 15"H 120"W 18"D Alumin Air Curtain |
|---|---|
| Width | 120 in |
| Phase | 3 |
| Max. Mounting Height | 12 ft |
| Air Curtain Finish | Powder Coated |
| Number of Motors | 3 |
| Height | 15 in |
| Air Curtain Air Velocity | 4,000 fpm |
| Voltage | 208/230 |
| Air Curtain Air Volume | 4,678 cfm |
| Air Curtain Max. Door Width | 10 ft |
| Air Curtain dBA @ 10 Feet | 66 dBA |
| Depth | 18 in |
| Air Curtain Heated | No |
| Air Curtain Housing Material | Steel |
| Hz | 60 |
| Requires | Hard Wiring |
| Motor Type | Permanent Split Capacitor |
| Standards | AMCA Certified, UL Listed |
| Motor Enclosure | Open Dripproof |
| Includes | Activation Switch, Factory Mounted Control Panel |
| Air Curtain Item | High Velocity Air Curtain |
| Number of Speeds | 1 |
| Motor HP | 0.5 |
| Housing Color | Gray |
| Max. Amps | 10.5/10.5 |
| Max. RPM | 1,680 |
| Overall Height | 15 in |
| Overall Depth | 18 in |
| Overall Width | 120 in |
| Control Type | Activation Switch |
| Finish | Powder Coated |
| Housing Material | Aluminum |
| Motor Horsepower per Motor | 0.5 HP |
| Full Load Current | 10.5 A |
| Maximum Air Volume | 4,678 cfm |
| HEPA Air Cleaning | No |
| Washdown | No |
| Assembly | Not Available |
| Series | IDC12 |
| Maximum Air Velocity | 5,166 fpm |
| Nozzle Width | 117 in |
| Drive Type | Direct Drive |
| Minimum Operating Temperature | Not Available |
| Electrical Connection | Hardwired |
| Power Cord Length | Not Available |
| For Outdoor Use | Yes |
| Includes Mounting Fasteners | No |
| Ultraviolet Air Cleaning | No |
| Mounting Height for Insect Control | 10 ft |
| Maximum Operating Temperature | Not Available |
| Maximum Speed | 1,680 rpm |
| Heated/Not Heated | Not Heated |
| Sanitation Certified | No |
| For Frame Opening Width | 10 ft |
| Nameplate Voltage | 208/240V AC |
| Heater Power Consumption | Not Applicable |
| Power Consumption | 1.55 kW |
| Sound Level @ 10 ft | 68 dBA |
| Grille Material | Aluminum |
| Mounting Hole Diameter | 1/2 in |
| Frequency | 60 Hz |
| Mounting Height for Temperature Control | 12 ft |
| Profile Type | Standard Profile |
| Air Temperature Rise | Not Applicable |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
