Gigatrue 550 Cat6, 550-Mhz Stranded Bulk
| Item | Ethernet Bulk Cable |
|---|---|
| Gauge/Conductor | 24 AWG |
| Standards | ANSI/TIA-568-C.2 Category 6, ISO/IEC 11801 Class E |
| Return Loss | 22.5 dB/100 m @ 100 MHz; 21 dB/100 m @ 200 MHz; 20.5 dB/100 m @ 250 MHz |
| PS-ACR | 32 dB @ 100 MHz |
| Attenuation (Maximum) | 23.6 dB/100 m (328.1 ft.) @ 100 MHz; 34.6 dB/100 m (328.1 ft.) @ 200 MHz; 39.1 dB/100 m (328.1 ft.) @ 250 MHz |
| Delay Skew (Maximum) | 25 ns/100 m (328.1 ft.) |
| NEXT (Minimum) | 45 dB/100 m (328.1 ft.) @ 100 MHz; 41 dB/100 m (328.1 ft.) @ 200 MHz; 39 dB/100 m (328.1 ft.) @ 250 MHz |
| Impedance | 100 +/-15 ohms @ 100 MHz; 100 +/-22 ohms @ 100 to 550 MHz |
| PS-NEXT (Minimum) | 43 dB/100 m @ 100 MHz; 39 dB/100 m @ 200 MHz; 37 dB/100 m @ 250 MHz |
| Mutual Capacitance | 56 pF/m |
| Resistance | 9.09 ohms/100 m |
| Frequency | Up to 550 MHz |
| Package Quantity | 1 |
