Cable de conexión, 4 pines, receptáculo, hembra.
| Item | Cordset |
|---|---|
| Cable Length | 2 m |
| Jacket Color | Yellow |
| End 1 Number of Pins | 4 |
| End 1 Thread | M12 |
| Wire Size | 22 AWG |
| End 2 Thread | Not Applicable |
| End 1 Connection Type | M12 |
| End 2 Connection Type | Bare Wire |
| NEMA Rating | 6P |
| Jacket Material | PVC |
| IP Rating | IP67, IP68 |
| Features | Patented Antivibration Feature to Prevent Loosening Under High Vibration Applications |
| Standards | CSA Certified, IEC, UL Listed |
| End 1 Keyway | Single |
| Max. Amps | 4 |
| End 1 Gender and Plug End | Female Right Angle |
| Number of Conductors | 4 |
| End 2 Gender and Plug End | Bare Wire |
| Keyway | Single |
| End 1 Number of Keyways | 1 |
| Number of Wires | 4 |
| Cable Jacket Material | PVC |
| End 1 Mounting Orientation | Angle |
| End 1 Gender | Female |
| Cordset Type | Single-Ended |
| Cable Jacket Color | Yellow |
| End 2 Gender | Not Applicable |
| Gender | Female-Pigtail |
| Current - Maximum per Contact | 4 A |
| Voltage - Maximum | 30V AC/DC |
| Wire/Cable Type | UL 2661 |
| Orientation | 90° to Pigtail |
| LED Indicator | PNP Sensors |
| Cable Diameter | 5.33 mm |
| Material - Connector Body | PVC |
| Coupling Style | Threaded |
| Material - O-Ring | Fluoro-elastomer |
| Temperature Range - Operating | -30°C to +90°C |
| CSA | LR6837 |
| Material - Cable Jacket | PVC |
| Material - Plating Mating | Gold |
| Poles | 4 |
| Material - Coupling Nut | Nickel-plated Brass |
| UL | E152210 |
| Color - Cable Jacket | Black |
| Wire Size AWG | 22 |
| Package Quantity | 1 |
