3/4" x 41/64" Red Wire Marking Sleeves
| Color | Red |
|---|---|
| Printer Series Compatibility | BBP72, i5100, i7100, IP Series, THT |
| Item | Precut Label Roll |
| Height | 41/64 in |
| Legend | None |
| Material | Brady B-342 Heat Shrink Polyolefin Double-Sided Print |
| Width | 3/4 in |
| Temp. Range | -67 to 275 deg F |
| Label Width | 3/8 in |
| Label Height | 3/4 in |
| Max. Wire Size | 0.32 in |
| For Use With | Thermal Transfer Printers |
| Labels per Roll | 2,000 |
| Shrink Ratio | 3:1 |
| Max. Lines of Print | Varies |
| Min. Wire Size | 1/8 in |
| Standards | MIL-STD-202, RoHS Compliant, SAE-AMS-DTL-23053/5C (Class 1), SAE-AS-81531, UL Recognized |
| Application | Wire and Cable Labeling |
| Adhesive | Non-Adhesive |
| Label Material | Polyolefin |
| Maximum Wire Gauge | 4 AWG |
| Label Color | Red |
| Product Type | Wire Marking Sleeve |
| Label Attachment Style | Heat Shrink Sleeve |
| Maximum Service Temperature | 275 deg F |
| Core Diameter | 3 in |
| Recommended Ribbon | IP-R6700-WT, R6700-WT |
| Material Properties | Heat-Shrinkable |
| Labels per Row | 2 |
| Resistance Properties | Chemical-Resistant, Cold-Resistant, Corrosion-Resistant, Fade-Resistant, Flame-Resistant, Humidity-Resistant, Smear-Resistant, UV-Resistant, Weather-Resistant |
| Compatible Mfr Part Number | IP-R6700-WT, R6700-WT |
| Label Media Format | Precut Roll |
| Minimum Wire Gauge | 12 AWG |
| Maximum Wire Diameter | 0.96 in |
| For Print Method | Thermal-Transfer |
| Double-Sided Printable | No |
| Label Finish | Matte |
| Material Series | B-342 |
| Adhesive Material | Not Applicable |
| Minimum Wire Diameter | 0.43 in |
| Minimum Service Temperature | -67 deg F |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
