Printable Shrink Tubing, 1.5" W, Blk
| Item | Printable Shrink Tubing,1.5" W,Blk |
|---|---|
| Shrink Ratio | 0.084 |
| Material | Heat-shrink Polyolefin |
| Color | Black |
| Finish | Matte |
| Suggested Ribbon Series | R6600, R4300, R6000 Halogen Free, R6400 |
| Resistance Properties | Chemical-Resistant; Corrosion-Resistant; Humidity-Resistant; Self-Extinguishing; UV-Resistant; Weather-Resistant |
| Dimensions | 0.439 in H |
| Recovered Diameter (mm/cm/m) | 3.2 mm |
| Height (mm/cm/m) | 11.15 mm |
| Dimensions (Metric) | 19.05 mm W x 11.15 mm H |
| Wire Diameter Range | 1/8 to 0.215 in |
| Printer Compatibility (Print) | BBP72, i7100, BBP12 |
| Sleeve Size (mm/cm/m) | 6.4 mm Dia x 19.1 mm W |
| Roll Width (mm/cm/m) | 38.1 mm |
| Markers per Roll | 1,000 |
| Height (in/ft/yd) | 0.439 in |
| Label Properties | Heat Shrink Sleeves |
| Maximum Wire Diameter (mm/cm/m) | 5.46 mm |
| Sleeve Width (mm/cm/m) | 19.1 mm |
| Vertical Repeat | 3/4 in |
| Maximum Service Temperature °F | 248 deg F |
| Maximum Wire Diameter (in/ft/yd) | 0.215 in |
| Diameter as Supplied (in/ft/yd) | 1/4 in |
| Minimum Service Temperature °C | -40 °C |
| Printer and Label Applications | Wire & Cable |
| Size - Width (mm) | 19.05 mm |
| Roll Width (in/ft/yd) | 1-1/2 in |
| Minimum Wire Gauge | 12 AWG |
| Material Properties | Heat-shrinkable |
| Sleeve Slits | Yes |
| Printable Sides | Single-Side Printable |
| Recovered Diameter (in/ft/yd) | 1/8 in |
| Applications | Electrical Labeling; Wire and Cable Labeling |
| Core Diameter (mm/cm/m) | 76.20 mm |
| Wire Gauge | 45,268 |
| Vertical Repeat (mm) | 19.05 mm |
| Maximum Service Temperature °C | 120 deg C |
| Diameter as Supplied (mm/cm/m) | 6.4 mm |
| Maximum Wire Gauge | 8 AWG |
| Printer Compatibility | BBP72, PR200Plus, PR300Plus, PR600Plus, i7100, BBP12, BBP11 |
| Dimensions 2 | 0.439 in H |
| Label/Media Format | Roll |
| Minimum Wire Diameter (in/ft/yd) | 1/8 in |
| Print Technology | Thermal Transfer |
| Recommended Ribbon | R6702-WT |
| Wire Gauge Range | 12 AWG to 8 AWG |
| For Use with Printer | BBP®72 Label Printer; BradyPrinter i7100; BRADYPRINTER PR Plus Series Label Printer; THT 3" Core Printer |
| Sleeve Size (in/ft/yd) | 1/4 in Dia x 3/4 in W |
| Web Width (mm/cm/m) | 89.00 mm |
| Minimum Wire Diameter (mm/cm/m) | 3.18 mm |
| Sleeve Width (in/ft/yd) | 3/4 in |
| Primary Noun, Basic Function | Sleeve |
| Minimum Service Temperature °F | -40 °F |
| Package Quantity | 1 |
