Printable Shrink Tubing, 2" W, Black
| Item | Printable Shrink Tubing,2" W,Black |
|---|---|
| Shrink Ratio | 0.1257 |
| Material | Heat-shrink Polyolefin |
| Color | Black |
| Wire Diameter Range | 3/4 to 1.45 in |
| Height (mm/cm/m) | 61.8 mm |
| Minimum Wire Diameter (mm/cm/m) | 19.05 mm |
| Dimensions 2 | 2.433 in H |
| Roll Width (mm/cm/m) | 50.8 mm |
| Core Diameter (mm/cm/m) | 76.20 mm |
| Maximum Wire Diameter (in/ft/yd) | 1.45 in |
| Maximum Wire Diameter (mm/cm/m) | 36.83 mm |
| Vertical Repeat | 3 in |
| Label Properties | Heat Shrink Sleeves |
| Printer and Label Applications | Wire & Cable |
| Material Properties | Flame-retardant; Heat-shrinkable |
| Printable Sides | Double-Side Printable |
| Resistance Properties | Chemical-Resistant |
| Suggested Ribbon Series | R6700 |
| Diameter as Supplied (in/ft/yd) | 1-1/2 in |
| Dimensions | 2.433 in H |
| For Use with Printer | BBP®72 Label Printer; BradyPrinter i7100; BRADYPRINTER PR Plus Series Label Printer; THT 3" Core Printer |
| Printer Compatibility (Print) | BBP72, i7100, i5100 |
| Height (in/ft/yd) | 2.433 in |
| Maximum Service Temperature °C | 130.6 deg C |
| Print Technology | Thermal Transfer |
| Recovered Diameter (mm/cm/m) | 19.1 mm |
| Sleeve Size (in/ft/yd) | 1-1/2 in Dia x 2 in W |
| Sleeve Size (mm/cm/m) | 38.1 mm Dia x 50.8 mm W |
| Primary Noun, Basic Function | Sleeve |
| Applications | Wire and Cable Labeling |
| Dimensions (Metric) | 50.80 mm W x 61.80 mm H |
| Sleeve Width (mm/cm/m) | 50.8 mm |
| Recovered Diameter (in/ft/yd) | 3/4 in |
| Web Width (mm/cm/m) | 89.00 mm |
| Sleeve Width (in/ft/yd) | 2 in |
| Roll Width (in/ft/yd) | 2 in |
| Printer Compatibility | BBP72, PR200Plus, PR300Plus, PR600Plus, i7100, IP300, IP600, i5100 |
| Label/Media Format | Roll |
| Minimum Service Temperature °C | -55 °C |
| Maximum Service Temperature °F | 267 deg F |
| Size - Width (mm) | 50.8 mm |
| Diameter as Supplied (mm/cm/m) | 38.1 mm |
| Minimum Wire Diameter (in/ft/yd) | 3/4 in |
| Minimum Service Temperature °F | -67 °F |
| Recommended Ribbon | IP-R6700-WT; R6700-WT |
| Package Quantity | 1 |
