Dispositivo de bloqueo, hembra, 20A 3 fases Wye 120/208V AC, 4 polos 4 mallas sin conexión a tierra, no NEMA, con terminal de tornillo.
| Color | Yellow |
|---|---|
| Application | Heavy Duty Industrial |
| Material | Composite |
| Type | Connector Body |
| Number Of Wires | 4-Wire |
| Environmental Conditions | Indoor Dry Unless Protected By Additional Means |
| Wire Size | #18 AWG to #8 AWG |
| Voltage Rating | 3 Phase Y 120/208 VAC |
| Conductor Range | #14 AWG to #12 AWG |
| Display Size | Standard Sized Product |
| Length | 2.11 in |
| Height | 3.73 in |
| Nema Rating | Non-NEMA |
| Material - Mounting Hardware | Cord Mounted |
| Amperage Rating | 20 A |
| Style | Internal Cord Clamp |
| Connectivity | Screw Terminals |
| Item Type | 20A Nylon Connector-For Replacement Use |
| Number Of Poles | 4-Pole |
| Insulation | Insulated Body |
| Temperature Rating | Maximum Continuous: 75° C; Minimum Continuous: -40° C w/o impact, -25° with impact. |
| Number Of Conductors | 4-Wire Non-Grounding |
| Package Quantity | 1 |
