Terminal de horquilla de vinilo de calibre 12-10 para tornillos #4 y #6.
| Wire Range | 12 to 10 AWG |
|---|---|
| Insulation Type | Vinyl |
| Stud Size | #4, #6 |
| Insulation Color | Yellow |
| Item | Fork Terminal |
| Max. Voltage | 600 V |
| Overall Length | 0.68 in |
| Connection Material | Copper |
| Standards | CSA Certified; UL467; UL Listed |
| Terminal Type | Ring Tongue |
| Application | For Commercial And Light Duty Industrial Control And Power Circuit Applications |
| Material | Copper |
| Wire Type | Solid or Stranded |
| Contact Plating Material | Tin Plated |
| Insulation Dia | 0.26 in |
| Conductor Size | 12 to 10 AWG |
| Insulation | Y |
| Plated | Yes |
| Physical Attribute - Tongue Type | Ring |
| Dimension - L Length Overall mm | 24 mm |
| Dimension - Pad Width inch | 0.31 in |
| Trade Name | VINYLUG™ |
| Dimension - Strip Length inch | 19/64 in |
| Dimension - B Length fraction | 17/50 in |
| Voltage - Maximum | 600 V |
| Conductor Type | CU C Str-Size |
| Connector Type | Ring Terminal |
| Standards - Industry Standards Met | UL467 |
| Color Code | Yellow |
| Conductor Range | #12 AWG to #10 AWG |
| Dimension - Length Overall inch | 0.95 in |
| Type | Ring Tongue |
| Dimension - Stud Size inch | #6 |
| Certification - CSA Approved | Yes |
| UL Listed | Yes |
| Dimension - Hole Size inch | 0.14 in |
| Dimension - Hole Size fraction | 18,445 |
| Dimension - Diameter Max Size inch | 0.28 in |
| Feature - Barrel Style | Shrouded |
| Plating Type | Tin |
| Industry Standard(s) | UL467 |
| Dimension - Bolt Size fraction | #6 |
| Dimension - B Length inch | 0.34 in |
| Dimension - Z inch | 0.2 in |
| Cable Insulation Diameter Maximum | 0.26 in |
| Physical Attribute - Number of Holes | 1 |
| Package Quantity | 1 |
