Terminale de 2 orificios para cable calibre 2/0AWG con tornillo de 1/4", flexible, cumple con la normativa RoHS.
| Connector Type | Terminal |
|---|---|
| Material | Copper |
| Color Code | Black |
| Gauge | 2/0 AWG |
| Application | For Flex Conductors |
| Conductor - Copper Flex G Size | 36557 |
| Dimension - B Length fraction | 13/16 in |
| Conductor - Copper Flex G Size Range | 36557 |
| Conductor - Copper Str Navy Size | 125 (61) |
| Certification - CSA Approved | Yes |
| Conductor - Copper DLO Size Range | 2/0 (375/#24) |
| Feature - Barrel Type | Standard |
| Conductor - Copper Flex I Size Range | 36557 |
| Voltage - Maximum | 35000 |
| Physical Attribute - Number of Holes | 2 |
| Dimension - Bolt Hole Size inch | 0.27 in |
| Conductor - Copper Flex H Size Range | 36557 |
| Dimension - Strip Length inch | 13/16 |
| Plated | Y |
| Dimension - N inch | 0.31 in |
| Dimension - Pad Width inch | 0.76 in |
| Type | YAV-L-NTFX |
| Die Index | 13 |
| Dimension - Z inch | 0.34 in |
| Plating Type | Tin Electro Plated |
| Dimension - D inch | 1.28 in |
| Conductor - Copper Flex M Size | 36557 |
| Rating - Minimum Voltage | 600 |
| Dimension - Length Overall inch | 2.56 in |
| Conductor - Copper Flex K Size | 36557 |
| Dimension - Diameter Min Size inch | 1.28 in |
| Dimension - Outside Diameter inch | 0.63 in |
| Dimension - Bolt Size fraction | 44930 |
| Conductor - Copper Str Size Range | 36557 |
| Physical Attribute - Tongue Angle | Straight |
| Conductor - CopperWeld Str Size | 2/0 F;2/0 G;2/0 J;2/0 K;2/0 V |
| Dimension - B Length inch | 0.81 in |
| Conductor - Copper Flex K Size Range | 36557 |
| Conductor - Copper Flex H Size | 36557 |
| Conductor - Copper DLO Size | 2/0 (375/#24) |
| Rating - KVA | 35 kV |
| Dimension - L Length Overall mm | 65 mm |
| Conductor - Copper Flex I Size | 36557 |
| Conductor - Copper Str Size | 36557 |
| Dimension - Stud Size inch | 44930 |
| Barrel | Short |
| Holes | 2 HOLE |
| Bolt Hole | 1/4 in |
| Package Quantity | 1 |
