Barra estándar de terminal flexible de 2 orificios, calibre 2/0, perno de 3/8 de pulgada y 1 pulgada de centro, cubierta con aislamiento negro ROHS.
| Connector Type | Terminal |
|---|---|
| Color Code | Black |
| Conductor - Copper Solid Size Range | 2/0 AWG |
| Physical Attribute - Tongue Type | Standard |
| Cable Rating | OSP |
| Rating - Minimum Voltage | 600 |
| Die Index | 13 |
| Dimension - Pad Width inch | 0.93 in |
| Conductor - Copper Flex H Size | 2/0 AWG |
| Conductor - Copper Str Navy Size | 125 Navy |
| Conductor - Copper Flex I Size Range | 2/0 AWG |
| Feature - Barrel Type | Standard |
| Dimension - Hole Size mm | 10 mm |
| Physical Attribute - Number of Holes | 2 |
| Dimension - Z inch | 0.43 in |
| Conductor - Copper Flex M Size | 2/0 AWG |
| Plated | Y |
| Certification - CSA Approved | Yes |
| Temperature Rating | 194 |
| Conductor - CopperWeld Str Size Range | 2/0 WELD |
| Dimension - B Length fraction | 13/16 in |
| Fiber Type | OM4, MM |
| Plating Type | Tin |
| Voltage - Maximum | 35000 |
| Lug Length X Tongue Width (In.) | 3.12 in x 0.93 in |
| Beveled Entry | Yes |
| Lug Material | Copper |
| Bolt Hole | 3/8 in |
| Stud Hole Spacing (In.) | 1 in |
| Type | Compression |
| Holes | 2 HOLE |
| Center Spacing | 1 in |
| Stud Hole Size (In.) | 3/8" |
| Conductor Size/Gauge | 2/0 AWG |
| Inspection Hole | Yes |
| Degree | Straight |
| Package Quantity | 1 |
