Abrazadera en "U" estándar de 45 grados para conductores de calibre 2, con tornillo de #2 y poste de 1/4" a 5/8" de distancia, aprobada para uso en exteriores y cumpliendo con la directiva RoHS.
| Connector Type | Terminal |
|---|---|
| Material | Copper |
| Color Code | Brown |
| Rating - KVA | 35 kV |
| Feature - Barrel Type | Standard |
| Type | Tin Plated, Standard Barrel |
| Dimension - Hole Size mm | 7 mm |
| Conductor - Material | Copper |
| Voltage - Maximum | 35000 |
| Plating Type | Electro Tin Plated |
| Dimension - Length Overall inch | 2.02 in |
| Conductor - Copper Str Navy Size | 60 (37) Navy |
| Dimension - Hole Size inch | 0.27 in |
| Dimension - Strip Length inch | 15/16 |
| Plated | Y |
| Dimension - L Length Overall mm | 51 mm |
| Industry Standard(s) | UL468A-468B |
| Physical Attribute - Tongue Angle | 45 Degree |
| Dimension - Z inch | 0.33 in |
| Dimension - Height inch | 1.15 in |
| Die Index | 10 |
| Dimension - Bolt Hole Size inch | 0.27 in |
| Dimension - N inch | 0.31 in |
| Conductor - Copper Str Size | 2 AWG |
| Dimension - D inch | 1.27 in |
| Physical Attribute - Number of Holes | 2 |
| Dimension - Outside Diameter inch | 0.42 in |
| Dimension - Pad Width inch | 0.6 in |
| Rating - Minimum Voltage | 600 |
| Conductor - Copper Str Navy Size Range | 60 (37) Navy |
| Standards - Industry Standards Met | UL468A-468B |
| Certification - CSA Approved | Yes |
| Dimension - B Length inch | 0.88 in |
| Temperature Rating | 194 |
| Dimension - Stud Size inch | 44930 |
| Holes | 2 HOLE |
| Bolt Hole | 1/4 in |
| Inspection Hole | Yes |
| Package Quantity | 1 |
