2H LUG KIT ESTÁNDAR BARRA #8 TIERRA/#6 SOL, #10 TORNILLO DE 5/8" EN EL CENTRO, INSPECCIÓN DE CABLEADO ROHS
| Connector Type | Terminal |
|---|---|
| Material | Copper |
| Color Code | Red |
| Type | Tin Plated, Standard Barrel |
| Dimension - L Length Overall mm | 46 mm |
| Industry Standard(s) | UL468A-468B |
| Dimension - Hole Size inch | 0.21 in |
| Rating - KVA | 35 kV |
| Conductor - Copper Str Size | 8 AWG |
| Dimension - N inch | 1/4 in |
| Voltage - Maximum | 35000 |
| Certification - CSA Approved | Yes |
| Dimension - Pad Width inch | 0.41 in |
| Dimension - Bolt Hole Size inch | 0.2 in |
| Temperature Rating | 194 |
| Physical Attribute - Tongue Angle | Straight |
| Conductor - Material | Copper |
| Conductor - Copper Str Size Range | 8 AWG |
| Plating Type | Tin Electro Plated |
| Rating - Minimum Voltage | 600 |
| Dimension - Hole Size mm | 5 mm |
| Feature - Barrel Style | Chamfered |
| Feature - Barrel Type | Standard |
| Dimension - B Length inch | 0.44 in |
| Dimension - Strip Length inch | 45123 |
| Application | For Code Conductor |
| Plated | Y |
| Dimension - Length Overall inch | 1.83 in |
| Dimension - Z inch | 0.26 in |
| Physical Attribute - Tongue Type | Standard |
| Conductor - Copper Str Navy Size | 23 (7) Navy |
| Dimension - Stud Size inch | #10 |
| Standards - Industry Standards Met | UL468A-468B |
| Conductor - Copper Str Navy Size Range | 23 (7) Navy |
| Dimension - Outside Diameter inch | 0.27 in |
| Dimension - D inch | 0.51 in |
| Die Index | 49 |
| Physical Attribute - Number of Holes | 2 |
| Inspection Hole | Yes |
| Stud Hole Spacing (In.) | 5/8" |
| Bolt Hole | 10MM |
| Holes | 2 HOLE |
| Beveled Entry | Yes |
| Lug Length X Tongue Width (In.) | 1.83 in x 0.41 in |
| Center Spacing | 5/8 in |
| Package Quantity | 1 |
