Conector de compresión de solamente un orificio para terminal de compresión, 250 kcmil.
| Cable Size | 250 kcmil |
|---|---|
| Connector Type | Standard Barrel |
| Width | 1.29 in |
| Material | Tin-Electro Plated Copper |
| Length | 2.93 in |
| Color Code | Red |
| Tongue Style | Standard |
| Peep Hole | Yes |
| Plate Material | Electro Tin |
| Item | One-Hole Lug Compression Connector |
| Die Code | 1,025 |
| Hole Center to End | 0.53 in |
| Standards | CSA Certified, UL 486A-486B, UL Listed |
| Barrel Length | Short |
| Stud Size | 1/2 in |
| Hole Center to Center | Not Applicable |
| Application | For Flex Conductor |
| Length (Straight Wireway) | 2.93 in |
| Conductor Size | 350 KCMIL |
| Rating - KVA | 35 kV |
| Conductor - Copper Flex M Size | 250 kcmil |
| UL Listed | Yes |
| Dimension - Hole Size mm | 13 mm |
| Physical Attribute - Tongue Angle | Straight |
| Conductor - Copper Flex K Size | 250 kcmil |
| Dimension - Stud Size fraction | 1 to 2 |
| Dimension - B Length fraction | 1.1111 in |
| Voltage Rating | 35 kV |
| Dimension - Hole Size inch | 0.53 in |
| Dimension - Pad Width inch | 1.29 in |
| Dimension - Bolt Size fraction | 1 to 2 |
| Dimension - B Length inch | 1.1 in |
| Dimension - L Length Overall mm | 74 mm |
| Dimension - Bolt Size inch | 0.5 |
| Physical Attribute - Tongue Type | Standard |
| Conductor - Copper Str Size Range | 350 kcmil |
| Feature - Barrel Style | Belled |
| Dimension - Hole Size fraction | 1 to 2 |
| Conductor - Copper Str Navy Size | 350 (91) Navy |
| Rating - Minimum Voltage | 600 |
| Finish Type | Tin-Plated |
| Conductor - Material | Copper |
| Dimension - N inch | 0.53 in |
| Dimension - Outside Diameter inch | 0.88 in |
| Conductor Type | CODE |
| Conductor - Copper DLO Size | 262.6 (650/#24) DLO |
| Dimension - Strip Length inch | 42372 |
| Certification - CSA Approved | Yes |
| Dimension - Z inch | 0.55 in |
| Feature - Barrel Type | Standard |
| Trade Name | HYLUGâ„¢ |
| Die Index | 18;1025 |
| Physical Attribute - Number of Holes | 1 |
| Voltage - Maximum | 35000 |
| Conductor - Copper Str Size | 350 kcmil |
| Conductor - Copper Flex I Size | 250 KCMIL |
| Dimension - Length Overall inch | 2.93 in |
| Type | Tin Plated, Standard Barrel |
| Dimension - Bolt Hole Size inch | 0.52 in |
| Plating Type | Tin Electro Plated |
| Industry Standard(s) | UL468A-468B |
| Standards - Industry Standards Met | UL468A-468B |
| Plated | Y |
| Package Quantity | 1 |
