22mm NEMA Mom. Illum. Pushbutton, Full Voltage, 12V AC/DC, Polyester Clamp Ring, Extended Lens, Red Lens, NO
| Mounting Diameter | 22mm |
|---|---|
| Operator/Switch Size | 22mm |
| Make Rating | 7200VA(AC)/138VA(DC) |
| Break Rating | 720VA(AC)/138VA(DC) |
| Ith-Thermal Current | 10A(AC)/5A(DC) |
| Device Rating | NEMA |
| NEMA Rating | Type 1,2,3,3R,4/4X,12,13 |
| IP Rating | IP65 |
| Action/Function | Momentary |
| Light Module | Full Voltage |
| Voltage | 12V AC/DC |
| Lamp Type | No Lamp |
| Bezel Material | Polyester |
| Cap/Lens Type | Extended |
| Cap/Lens Color | Red |
| Contact Configuration | 1 N.O. |
