Conduit Body, Type LL, FM8, 1-1/4 in., PVC
| Item | Conduit Outlet Body |
|---|---|
| Hazardous Location | No |
| Hub Size | 1-1/4 in |
| Conduit Outlet Body Material | Iron |
| Material | Aluminum |
| Conduit Outlet Body Style | LL |
| Conduit Outlet Body Capacity | 24 cu in |
| Includes | Screws |
| Conduit Outlet Body Hub Size | 1-1/4 in |
| For Use With | Threaded Conduit |
| Conduit Outlet Body Hub Style | Threaded |
| Special Features | Interior Urethane Coating, Corrosion Resistant |
| Wall Thickness | 1-3/4 in |
| Back Type | Flat |
| Standards | CSA C22.2 No. 18, NEMA 4X Rated, UL Listed Standard 514B |
| Color | Black |
| Form | Form 8 |
| Cover Included | Yes |
| Compatible Conduit Trade Size | 1-1/4 in |
| Number of Hubs | 2 |
| Body Capacity | 24 cu in |
| Body Style | LL |
| Overall Height | 2-7/16 in |
| Overall Width | 3-3/16 in |
| Trade Size | 1-1/4 in |
| Hub Style | Threaded |
| Body Type | LB Style |
| Finish | PVC Coated |
| Connection Type | Threaded |
| Height | 2.35 in |
| Width | 3.23 in |
| Length | 7.79 in |
| Standard | UL 514B/ CSA C22.2 No.18 |
| Application | Act as pull outlets for conductors being installed, Provide openings for making splices and taps in conductors, Connect conduit sections, Provide taps for branch conduit runs, Provide for access to conductors for maintenance and future, system changes |
| Type | PVC COATED FORM 7 LL FITTINGS |
| Package Quantity | 1 |
