Conduit Body, Type T, FM8, 1/2 in., PVC
| Item | Conduit Outlet Body |
|---|---|
| Hub Size | 1/2 in |
| Hazardous Location | No |
| Conduit Outlet Body Material | Iron |
| Conduit Outlet Body Style | T |
| Material | Aluminum |
| Conduit Outlet Body Capacity | 5 cu in |
| Includes | Screws |
| Conduit Outlet Body Hub Size | 1/2 in |
| For Use With | Threaded Conduit |
| Conduit Outlet Body Hub Style | Threaded |
| Special Features | Interior Urethane Coating, Corrosion Resistant |
| Back Type | Flat |
| Standards | CSA C22.2 No. 18, NEMA 4X Rated, UL Listed Standard 514B |
| Color | Black |
| Form | Form 8 |
| Overall Width | 2-3/16 in |
| Trade Size | 1/2 in |
| Connection Type | Threaded |
| Hub Style | Threaded |
| Number of Hubs | 3 |
| Body Type | LB Style |
| Compatible Conduit Trade Size | 1/2 in |
| Body Capacity | 5 cu in |
| Overall Height | 1-13/16 in |
| Finish | PVC Coated |
| Body Style | T |
| Cover Included | Yes |
| Width | 1.46 in |
| Height | 3.57 in |
| Length | 6.69 in |
| Type | PVC COATED FORM 8 FITTINGS |
| Application | Act as pull outlets for conductors being installed, Provide openings for making splices and taps in conductors, Connect conduit sections, Provide taps for branch conduit runs, Provide for access to conductors for maintenance and future, system changes |
| Package Quantity | 1 |
