Circuit Breaker, A Series, 10A, 1 Pole, 250V AC, 1.5kA at 120/240V AC, Medium Curve
| CAD Available | Yes |
|---|---|
| Item | Circuit Breaker |
| Series | A |
| Amps | 10A |
| Number of Poles | 1 |
| AC Voltage Rating | 250V AC |
| Circuit Breaker Type | Magnetic |
| Phase | 1 |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | Threaded Insert |
| Max. AIR Rating | 1.5kA at 120/240V AC |
| Trip Type | Series Trip |
| Terminal Connection | #10-32 Screw |
| Width | 3/4 in |
| Depth | 2.69 in |
| Height | 2 in |
| DC Voltage Rating | 65V DC |
| Curve Type | Medium |
| AIR @ 65VDC | 3.0kA |
| AIR @ 240VAC | 1.5kA |
| AIR @ 120VAC | 1.5kA |
| AIR @ 125VDC | Not Rated |
| Standards | CSA, UL 1077, UL 1500 |
| Max. Wire Size | Not Specified |
| Actuator Legend | On/Off |
| Panel Cutout Size | 2.187 in x 0.77 in |
| Mounting Hole Thread Size | #6-32 |
| Max. Panel Thickness | 0.1 in |
| Actuator Color | Black |
| Length (Straight Wireway) | 2 in |
| Switch Type | Toggle |
| Length | 2 in |
| Mounting Type | Panel, #6-32 Thread |
| Package Quantity | 1 |
