Takes (12) RP.X 1204.. Inserts, 0.236" Max Depth, Through Coolant
| Minimum Cutting Diameter (Decimal Inch) | 5.5280 |
|---|---|
| Maximum Cutting Diameter (Decimal Inch) | 6.0000 |
| Maximum Depth of Cut (Decimal Inch) | 0.2360 |
| Arbor Hole Diameter (mm) | 1.50 |
| Compatible Insert Size Code | RP.X 1204.. |
| Maximum Ramping Angle | 0.00 |
| Cutter Style | A251 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw; Clamp |
| Series | A251-12 |
| Hub Diameter (Inch) | 3-3/4 |
| Hub Diameter (Decimal Inch) | 3.7500 |
| Overall Height (Inch) | 3-3/4 |
| Overall Height (Decimal Inch) | 3.7500 |
| Maximum RPM | 8300 |
| Tool Application | Face Milling |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Number Of Cutter Inserts | 12 |
| Coolant Through | Yes |
| UNSPSC Code | 27112803 |
| Country of Origin | Bulgaria |
| MSC Number | MSC# 33951260 |
