Uses 5 XPLX Inserts, Coolant Through
| Minimum Cutting Diameter (mm) | 32.00 |
|---|---|
| Maximum Cutting Diameter (mm) | 32.00 |
| Maximum Depth of Cut (mm) | 0.80 |
| Toolholder Style | CHFC |
| Shank Type | Cylindrical |
| Shank Diameter (Decimal Inch) | 25.0000 |
| Shank Diameter (Inch) | 25 |
| Shank Diameter (mm) | 25.00 |
| Maximum Ramping Angle | 1.30 |
| Compatible Insert Style | XPLX |
| Compatible Insert Size Code | 0603 |
| Insert Holding Method | Screw |
| Number Of Cutter Inserts | 5 |
| Overall Length (Decimal Inch) | 225.0000 |
| Overall Length (Inch) | 225 |
| Overall Length (mm) | 225.00 |
| Series | CHFC-06 |
| Flute Type | Straight |
| Maximum RPM | 3900 |
| Head Length (mm) | 60.00 |
| Functional Length (mm) | 60.00 |
| Tool Application | Facing; Milling |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Number Of Flutes | 5 |
| Coolant Through | Yes |
| UNSPSC Code | 27112803 |
| Country of Origin | Bulgaria |
| MSC Number | MSC# 33952151 |
