Uses 4 XPLX Inserts, 0.0310" Max Depth, Coolant Through
| Minimum Cutting Diameter (Inch) | 1 |
|---|---|
| Minimum Cutting Diameter (Decimal Inch) | 1.0000 |
| Maximum Cutting Diameter (Decimal Inch) | 1.0000 |
| Maximum Cutting Diameter (Inch) | 1 |
| Maximum Depth of Cut (Decimal Inch) | 0.0310 |
| Toolholder Style | GHFC |
| Shank Type | Modular Connection |
| Shank Diameter (mm) | 12.00 |
| Maximum Ramping Angle | 2.00 |
| Compatible Insert Style | XPLX |
| Compatible Insert Size Code | 0603 |
| Insert Holding Method | Screw |
| Number Of Cutter Inserts | 4 |
| Overall Length (Decimal Inch) | 2.3700 |
| Series | GHFC-06 |
| Flute Type | Straight |
| Maximum RPM | 17000 |
| Modular Connection Size | M12 |
| Head Length (Decimal Inch) | 0.4213 |
| Functional Length (Decimal Inch) | 0.4213 |
| Tool Application | Facing; Milling |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Number Of Flutes | 4 |
| Coolant Through | Yes |
| UNSPSC Code | 27112803 |
| Country of Origin | Bulgaria |
| undefined | undefined |
| MSC Number | MSC# 33952029 |
