Takes (3) XDLX 09T3.. Inserts, Through Coolant
| Minimum Cutting Diameter (Decimal Inch) | 0.7902 |
|---|---|
| Maximum Cutting Diameter (Decimal Inch) | 1.0000 |
| Maximum Depth of Cut (Decimal Inch) | 0.0390 |
| Arbor Hole Diameter (Decimal Inch) | 1.0000 |
| Compatible Insert Size Code | XDLX 09T3.. |
| Maximum Ramping Angle | 2.00 |
| Cutter Style | CHFC |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Series | CHFC-09 |
| Maximum Body Diameter (Decimal Inch) | 1.0000 |
| Overall Height (Inch) | 8 |
| Overall Height (Decimal Inch) | 8.0000 |
| Maximum RPM | 9000 |
| Tool Application | Plunging; Milling; Ramping; Face Milling |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Number Of Cutter Inserts | 3 |
| Number Of Flutes | 3 |
| Coolant Through | Yes |
| UNSPSC Code | 27112803 |
| Country of Origin | Bulgaria |
| MSC Number | MSC# 33952086 |
