Takes (6) XDLX 09T3.. Inserts, Through Coolant
| Minimum Cutting Diameter (Decimal Inch) | 2.1850 |
|---|---|
| Maximum Cutting Diameter (Decimal Inch) | 2.5000 |
| Maximum Depth of Cut (Decimal Inch) | 0.0390 |
| Arbor Hole Diameter (Decimal Inch) | 0.7500 |
| Compatible Insert Size Code | XDLX 09T3.. |
| Maximum Ramping Angle | 0.60 |
| Cutter Style | AHFC |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw; Clamp |
| Series | AHFC-09 |
| Maximum Body Diameter (Decimal Inch) | 2.5000 |
| Overall Height (Inch) | 1-3/4 |
| Overall Height (Decimal Inch) | 1.7500 |
| Maximum RPM | 20500 |
| Tool Application | Face Milling |
| Primary Workpiece Material | Universal |
| Number Of Cutter Inserts | 6 |
| Number Of Flutes | 6 |
| Coolant Through | Yes |
| UNSPSC Code | 27112803 |
| Country of Origin | Bulgaria |
| undefined | undefined |
| MSC Number | MSC# 19726660 |
