Uses (3) Inserts, Through Coolant, 35 mm OAL
| Cutting Diameter (mm) | 40.00 |
|---|---|
| Overall Length (mm) | 35.00 |
| Maximum Depth of Cut (mm) | 10.00 |
| Cutter Style | GHSC |
| Shank Type | Modular Connection |
| Shank Diameter (mm) | 16.00 |
| Insert Holding Method | Screw |
| Maximum Ramping Angle | 4.8 |
| Tool Material | Steel |
| Series | GHSC-11 |
| Flute Type | Straight |
| Lead Angle | 90 |
| Head Length (mm) | 35.00 |
| Modular Connection Size | 16.00 mm |
| Maximum RPM | 39800 |
| Tool Application | Facing; Shouldering; Slotting |
| Primary Workpiece Material | Universal |
| UNSPSC Code | 27112803 |
| Usable Length (mm) | 35.00 |
| Number Of Flutes | 3 |
| Number Of Cutter Inserts | 3 |
| Coolant Through | Yes |
| Country of Origin | Bulgaria |
| undefined | undefined |
| MSC Number | MSC# 79975306 |
