Uses 6, SNHU 1204 Inserts, Through Coolant, Series A491-12
| Minimum Cutting Diameter (mm) | 80.00 |
|---|---|
| Maximum Cutting Diameter (mm) | 80.00 |
| Maximum Depth of Cut (mm) | 8.00 |
| Arbor Hole Diameter (mm) | 27.00 |
| Compatible Insert Size Code | SNHU 1204 |
| Cutter Style | A491 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Lead Angle | 90 |
| Rake | Negative |
| Series | A491-12 |
| Maximum Ramping Angle | 0.00 |
| Overall Height (Decimal Inch) | 50.00 |
| Hub Diameter (mm) | 58.00 |
| Tool Application | Facing; Shouldering; Slotting |
| Primary Workpiece Material | Universal |
| UNSPSC Code | 27112803 |
| Toolholder Material | Steel |
| Coolant Through | Yes |
| Number Of Cutter Inserts | 6 |
| Number Of Flutes | 6 |
| Country of Origin | Bulgaria |
| MSC Number | MSC# 12816419 |
