Uses 4, ZNHW 1205.. Inserts, Through Coolant, Series AHPC-12
| Minimum Cutting Diameter (mm) | 63.00 |
|---|---|
| Maximum Cutting Diameter (mm) | 63.00 |
| Maximum Depth of Cut (mm) | 11.00 |
| Arbor Hole Diameter (mm) | 22.00 |
| Compatible Insert Size Code | ZNHW 1205.. |
| Cutter Style | AHPC |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Lead Angle | 90 |
| Rake | Neutral |
| Series | AHPC-12 |
| Maximum Ramping Angle | 0.00 |
| Overall Height (Decimal Inch) | 22.00 |
| Hub Diameter (mm) | 49.00 |
| Tool Application | Facing; Shouldering |
| Primary Workpiece Material | Non-Ferrous Metal |
| UNSPSC Code | 27112803 |
| Coolant Through | Yes |
| Number Of Cutter Inserts | 4 |
| Number Of Flutes | 4 |
| Country of Origin | Bulgaria |
| undefined | undefined |
| MSC Number | MSC# 12876413 |
