Carbon Hexagon Rethreading Die 0650 Cle-Line 1/2-20UNF
| Item | Hex Threading Die |
|---|---|
| Die Shape | Hex |
| Thread Type | UNF |
| Die Thread Size | 1/2"-20 |
| Die Material | Carbon Steel |
| Die Thickness | 1/2 in |
| Thread Direction | Right Hand |
| Overall Width | 1-1/16 in |
| Hex Size (In.) | 1-1/16 |
| Application | Machine Threading or Die Stock Hand Threading |
| Size | 1/2" |
| Pitch | 20 |
| Thickness (In.) | 1/2 |
| Material | Steel |
| Material - Machining | Carbon Steel |
| Outside Dia. | 1-1/16 in |
| Secondary Material Application | Stainless Steel |
| Threads per Inch | 20 |
| Thread Size | 1/2"-20 |
| Primary Material Application | All Materials |
| Finish - Machining | Bright |
| Thread Standard | UNF |
| Die Type | Solid |
| Primary Material Application ISO Code | K, N, P, H, M, S, O |
| Secondary Material Application ISO Code | M |
| Hex Size | 0.9563 in |
| For Tool Type | Rethreading |
| Package Quantity | 1 |
