Displacement Connector, 26-19AWG, PK100
| Color | Yellow |
|---|---|
| Max. Voltage | 600 V |
| Application | Moisture Resistant |
| Insulation Material | Polypropylene |
| Connector Type | Pigtail |
| Wire Range (Run) | 26 to 19 AWG |
| Crimping Tool | 4DYX1 |
| Standards | UL Listed |
| Max. Temp. | 140 deg F |
| Capacity | 26 to 19 AWG |
| Wire Range (Tap) | 26 to 19 AWG |
| Wire Type | Telecommunications |
| Fill Material | Gel |
| Max. Insulation Dia. | 0.082 in |
| Flame Retardant | No |
| Number of Ports | 2 |
| Item | Insulation Displacement Connector |
| Contact Finish | Not Applicable |
| Maximum Run Conductors | 2 |
| Contact Material | Not Applicable |
| Compatible Installation Tool Model Number | 4DYX1 |
| Minimum Tap Wire Size | 26 AWG |
| Maximum Tap Wire Size | 19 AWG |
| Maximum Run Wire Size | 19 AWG |
| Maximum Tap Wire Insulation Diameter | 0.082 in |
| Maximum Tap Conductors | 2 |
| Minimum Run Wire Size | 26 AWG |
| Maximum Run Wire Insulation Diameter | 0.04 in |
| UL 94 Flammability Rating | Not Applicable |
| RoHS Compliant | Yes |
| Package Quantity | 100 |
