Interruptor de acción rápida en miniatura, actuador de palanca, 1NC, 5A a 120V CA de capacidad de contacto.
| Item | Miniature Snap Action Switch |
|---|---|
| Actuator Type - Snap Action Switch | Lever |
| AC Contact Rating - Snap Action Switch | 5 A @ 120 V |
| DC Contact Rating - Snap Action Switch | 5 A @ 28 V |
| Contact Form- Switches | 1NO |
| Lever Actuator Length - Snap Action Switch | Not Applicable |
| Height - Snap Action Switch | 2.06 in |
| Width - Snap Action Switch | 0.8 in |
| Depth - Snap Action Switch | 0.94 in |
| Housing Material | Neoprene Rubber Encapsulated |
| Depth | 0.94 in |
| Electrical Connection - Snap Action Switch | Lead Wires |
| Contact Form | 1NO |
| Series | K1006 |
| Includes | Neoprene Rubber Encapsulated |
| Terminal Type | Lead Wires |
| Type of Actuator | Lever |
| Current Rating | 5 A |
| Watertight - Snap Action Switch | Yes |
| Height | 2.06 in |
| Release Force | Not Applicable |
| AC Contact Rating | 5 A @ 120 V |
| DC Contact Rating | 5 A @ 28 V |
| Resistance Properties | Watertight |
| Operating Force - Maximum | 48 ozf |
| Overall Height | 2.06 in |
| Differential Travel - Minimum | Not Applicable |
| Overall Depth | 0.94 in |
| Differential Travel - Maximum | Not Applicable |
| Body Depth | 0.94 in |
| Actuator Style | Lever |
| Body Width | 0.8 in |
| Overall Width | 0.8 in |
| Roller Adjustability | Fixed |
| Body Material | Neoprene Rubber |
| Overtravel | 1/4 in |
| Lever Actuator Length | Not Applicable |
| Pretravel | Not Applicable |
| Center Mounting Hole Distance | Not Applicable |
| Roller Position | Top |
| Roller Diameter | Not Applicable |
| Operating Force - Minimum | 16 ozf |
| Roller Material | Neoprene Rubber |
| Body Height | 2.06 in |
| Electrical Connection | Lead Wires |
| Roller Width | 0.31 in |
| Package Quantity | 1 |
