Uses (2) APET 1003..;XPET 1003.. Inserts, Through Coolant, 4.78" OAL
| Cutting Diameter | 3/4 |
|---|---|
| Overall Length (Decimal Inch) | 4.7800 |
| Maximum Depth of Cut (Decimal Inch) | 0.3500 |
| Cutter Style | SSER |
| Shank Type | Weldon Flat |
| Shank Diameter (Decimal Inch) | 1.0000 |
| Shank Diameter (Inch) | 1 |
| Insert Holding Method | Screw |
| Tool Material | Steel |
| Lead Angle | 90 |
| Shank Length (Decimal Inch) | 2.2800 |
| Head Length (Decimal Inch) | 2.5 |
| Insert Compatibility | APET 1003..; XPET 1003.. |
| UNSPSC Code | 27112803 |
| Number Of Flutes | 2 |
| Usable Length (Decimal Inch) | 2.5000 |
| Number Of Cutter Inserts | 2 |
| Coolant Through | Yes |
| Country of Origin | UNITED STATES |
| MSC Number | MSC# 76628650 |
