Axial Fan Kit 3 1/2 in D, 120V AC, 429/496 cfm
| Blade Material | Polycarbonate |
|---|---|
| CFM @ 0.000-In. SP | 85/95 cfm |
| Depth | 3-1/2 in |
| Housing Material | Cast Aluminum |
| Watts | 34/37 W |
| Includes | Fan, Steel Wire Guard, Cord Set with NEMA 1-15 Plug |
| Voltage | 120V AC |
| Motor Insulation | Class A |
| Hz | 50/60 Hz Hz |
| Diameter | 10 in |
| Motor Design | PSC |
| Electrical Connection - Fans | Terminals |
| Thermal Protection | Thermal Protection |
| Mounting Position | Vertical or Horizontal |
| Max. Ambient Temp. | 150 deg F |
| Mounting Eye O.C. | 9-11/16 in |
| IP Rating | 20 |
| Amps | 0.22/0.24 A |
| Bearing Type | Ball |
| RPM | 1400/1650 RPM |
| Color | Black |
| Item | Axial Fan Kit 3 1/2 in D |
| Standards | cULus Recognized |
| Environmental Applications | Equipment Cooling |
| Fan Shape | Round |
| Sound Level | 52/58 |
| Fan Cord Length | 72 in |
| Country of Origin (subject to change) | Taiwan, Province of China |
| Package Quantity | 1 |
