DAYTON Alu/Steel 8"H 19.25"W Exhst Fan
| Control Method - Roof Ventilators | Automatic |
|---|---|
| Max. Attic Area (Sq.-Ft.) | 1,500 sq ft |
| Item - Roof Ventilators | Exhaust Ventilator |
| Hz | 60 |
| HP | 1/10 HP |
| Amps | 1 |
| RPM | 1,550 |
| CFM @ 0.000-In. SP | 1,095 |
| CFM @ 0.125-In. SP | 770 cfm |
| Free Air Intake Required (Sq.-Ft.) | 3.5 sq ft |
| Opening Required (In.) | 16-3/4 X 16-3/4 |
| Thermostat Temp. (Deg. F) | 80 to 130 |
| Power Method - Roof Ventilators | 120V |
| Includes | Guard, Shutter, Thermostat |
| Item | Attic Exhaust Fan |
| Mounting Location - Roof Ventilators | Gable |
| Blade Material | Aluminum |
| Dome Diameter | Not Applicable |
| Control Type | Thermostat |
| Current | 1 A |
| Maximum Attic Area | 1,500 sq ft |
| Dome Width | Not Applicable |
| Power Source | Electric Motor |
| Overall Height | 17 in |
| Rough Opening Length | 17 in |
| Rough Opening Width | 17 in |
| Dome Shape | Not Applicable |
| Nameplate Voltage | 120V AC |
| High-Efficiency Motor | No |
| Rough Opening Diameter | Not Applicable |
| Maximum Motor Speed | 1,550 rpm |
| Airflow @ Static Pressure | 770 cfm @ 1/8 in |
| Includes Humidistat | No |
| Fire Safety Shut-Off | No |
| Housing Material | Aluminum |
| Overall Width | 17 in |
| Maximum Fan Speed | 1,550 rpm |
| Airflow @ 0.000 in SP | 1,095 cfm |
| Exhaust Airflow @ 0.000 in SP | 1,095 cfm |
| Motor Horsepower | 0.1 HP |
| Thermostat Temperature Range | 80 to 130 deg F |
| Wattage | 103 W |
| Rough Opening Shape | Square |
| Overall Length | 8 in |
| For High-Static Pressure Applications | No |
| Includes Shutter | Yes |
| Frequency | 60 Hz |
| Includes Thermostat | Yes |
| Includes Motor | Yes |
| Exhaust Airflow @ 0.125 in SP | 770 cfm |
| Country of Origin (subject to change) | China |
| Package Quantity | 1 |
