General Purpose Transformer, 9 kVA, NEMA 3R, 115°C, 120/208V AC, 240V AC
| Item | General Purpose Transformer |
|---|---|
| Input Voltage - Transformer | 240V AC |
| Mounting - Transformer | Wall |
| Hz - Electrical | 60 |
| IP Rating | IP54 |
| Outdoor Rated - Transformer | Yes |
| Winding Material | Aluminum |
| Color | Gray |
| Width | 16.93 in |
| Enclosure Material | Steel |
| Enclosure Finish | Powder Coated |
| Standards | RoHS, UL Listed |
| Output Voltage - Transformer | 120/208V AC |
| Temp. Rise | 115 deg C |
| Voltage Function - Transformer | Step Down, Step Up |
| Phase - Electrical | 3 |
| VA Rating - Transformer | 9 kVA |
| Enclosure Rating | NEMA 3R |
| Height | 15.9 in |
| Winding Material - Transformer | Aluminum |
| Depth | 10 in |
| Includes | Not Applicable |
| Sound Level | 40 dB |
| Package Quantity | 1 |
